Knipex 9R 471 001 3 Screw Extractor Double Edged Size 1

Non-slip and dual-edged engagement with the broken screw or bolt that needs to be removed

Features

• Unique hex head design works well with all standard hex sockets and extensions or box wrenches, eliminating the problem of rounded corners
• Can be turned in clockwise or counterclockwise direction (for right-and left-hand threads)
• For unscrewing ruined screws and bolts without damaging threads
• Tip has a built-in center punch pin to mark the center point
• Drill a hole in the broken fastener with appropriate size drill bit
• Tap extractor into hole and use a socket or wrench to loosen the fastener
• Tapered flute design
• Black-Oxide, cutting edges polished
• Made of high-strength chrome vanadium steel

Specifications

• Manufacturer Part Number: 9R 471 001 3
• Material Type: Chrome Vanadium Steel
• Surface Finish: Black-oxide
• 1000V Insulated: No
• Tethered Enabled: false
• Color: Black
• Nominal Length: 2 1/4"
• Tool Nominal Length: 2.25"
• Tool Length: 2.25"
• Tool Width: 0.3"
• Tool Height: 0.2"
• Tool Weight: 9 g (0.02 lb)
• Blade Diameter: 1/8" to 3/16"
• Wrench Size: 1/4"
• Screw Size-Inches: 3/16" to 1/4"
• Screw Size: M5 to M6
• Set Part Number: 9R 471 900 3|9R 471 903 3|9R 471 904 3
• UPC: 843221019808
